Description
Specifications:
| Compatibility | 3U OpenVPX (Vita 64, VITA 48, VITA 65-compliant) |
|---|---|
| Weight | 317.529g (11.2 oz) |
| CPU | Intel® Atom™ E3845 |
| Operating System | Linux 32/64-bit, VxWorks, WEC 7, WES 7/8, Windows 7/8 32/64-bit |
| Memory | 2GB RAM |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| PCI Express | Two Reference clock outputs, Two x4 PCIe Gen3.0 Capable Ports |
| Network | 2x 1000 BASE-X ports, 3x 10/100/1000 BASE-T ports |
| USB | Up to eight USB 2.0 (Hi-Speed) ports, Up to two USB 3.0 (SuperSpeed) ports |
| Storage | 2x SATA |
| Display | 1x DisplayPort |
| Audio | 1x stereo input, 1x stereo output |
| Serial | 2x RS-232 |
| General Purpose | 4x GP Inputs, 4x GP Outputs |
Ordering information:
VPG001 GraphiteVPX/CPU – 3U VPX SBC
