MPL’s CEC20 FAMILY RANGE
NewsUltra Compact & Rugged Embedded Computers
In demanding industrial, transportation, and defense environments, size, reliability, and computing power cannot be compromised. The CEC20 Family delivers an ideal combination of low-power Intel Atom x6000 performance, rugged construction, and modular flexibility in an ultra-compact footprint.
Designed and engineered in Switzerland, the CEC20 is built to operate reliably under extreme conditions while meeting rigorous standards like EN50155 (Railway), IEC 60945 (Maritime), and MIL-STD-810 (Defense).
Built for Secure, Long-Term Operations
Security and longevity are central to the CEC20 design. Built with hardware-based TPM 2.0 support, a customizable BIOS, and Intel Out-of-Band (OOB) Remote Management, the platform ensures secure and manageable remote operations.
Key Highlights:
- Driven by the Intel® Atom® x6000 Series
- Features 2.5 GbE network interfaces, up to 32 GB DDR4 RAM, and high-speed onboard soldered NVMe flash storage (240GB)
- Equiped with an M.2 Key-B slot and high-density expansion connectors (supporting PCIe, USB, and I²C interfaces)
- Housing options: (DIN-Rail, MIL enclosure, Open Frame)
Target Applications
The CEC20 handles tough workloads across industries:
- Industrial Automation & Edge Computing
- Railway & Transportation Systems (EN50155)
- Maritime Operations (IEC 60945)
- Defense & Avionics (MIL-COTS)
Ready to Upgrade Your Embedded Solution?
Explore detailed specifications in official datasheet or contact our team directly at: [email protected]
