Description
Dane techniczne:
| Pre-integrated with: • NVIDIA® Jetson Orin™ Nano (Supporting Super Mode) • NVIDIA® Jetson Orin™ NX (Supporting Super Mode) • NVIDIA® Jetson AGX Orin™ |
|
| Networking | 1x 1000BASE-T (GbE / RJ-45) |
| USB | 1x USB 3.2 USB Type-C w/ OTG |
| Storage | 1x NVMe M.2 M-Key 2280 Slot |
| Debug | UART, Reset, Force Recovery via Debug Header |
| Input Power | +12V to +17V DC |
| Display Output | N/A (Headless / Network Node) |
| Mechanical Information | Jetson Orin™ Nano/NX Variants: • Active: 118.32mm x 77.81mm x 52.86mm (4.658″ x 3.063″ x 2.081″) • Passive: 118.32mm x 77.81mm x 51.66mm (4.658″ x 3.063″ x 2.034″)Jetson AGX Orin™ Variants: • Active: 121.82mm x 117.81mm x 99.19mm (4.796″ x 4.638″ x 3.905″) • Passive: 121.82mm x 117.81mm x 78.19mm (4.796″ x 4.638″ x 3.078″) |
| Thermals | Active or Passive Options Available |
| Operating Temperature | 0°C to +50°C (32°F to +122°F) |
| Weight | Jetson AGX Orin Active: TBD Jetson AGX Orin Passive: TBD Jetson Orin NX/Nano Active: 317g Jetson Orin NX/Nano Passive: 316g |
| Warranty and Support | 1 Year Warranty and Free Support |
Ordering Information
CORE01-02 NVIDIA® Jetson AGX Orin™ 32GB, Active 0.5TB
CORE01-06 NVIDIA® Jetson AGX Orin™ 64GB, Active 0.5TB
CORE02-02 NVIDIA® Jetson AGX Orin™ 32GB, Passive 0.5TB
CORE02-06 NVIDIA® Jetson AGX Orin™ 64GB, Passive 0.5TB
CORE03-02 NVIDIA® Jetson Orin™ NX 8GB, Active 0.5TB
CORE03-05 NVIDIA® Jetson Orin™ NX 16GB, Active 0.5TB
CORE03-08 NVIDIA® Jetson Orin™ Nano 4GB, Active 0.5TB
CORE03-11 NVIDIA® Jetson Orin™ Nano 8GB, Active 0.5TB
CORE04-02 NVIDIA® Jetson Orin™ NX 8GB, Passive 0.5TB
CORE04-05 NVIDIA® Jetson Orin™ NX 16GB, Passive 0.5TB
CORE04-08 NVIDIA® Jetson Orin™ Nano 4GB, Passive 0.5TB
CORE04-11 NVIDIA® Jetson Orin™ Nano 8GB, Passive 0.5TB
Cables/Accessories
MSG119 Power Supply, Jetson AGX Orin variant
MSG120 Power Supply, Jetson Orin NX/Nano variant
CBG788 Serial Debug Cable, USB-UART 3.3V Cable
