Opis
Dane techniczne:
| CPU | 64-bit ARM® A57 CPUs |
|---|---|
| GPU | NVIDIA® Pascal™ |
| Operating System | 64bit Linux Ubuntu v14.04 LTS |
| Memory | 8GB RAM |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Power Requirements | +12V Input, 3V3_AUX (VS2 is not used), 5V (VS3) |
| Network | 2x 10/100/1000 BASE-T ports |
| USB | Up to three USB 2.0 (Hi-Speed) ports, Up to two USB 3.0 (SuperSpeed) ports |
| Storage | 1x SATA 2.0 Port |
| Display | 1x HDMI, Supports up to HDMI 2.0 UHD 4K [2160p] at 60Hz |
| Video Encode | 4K @ 60Hz |
| Video Decode | 4K @ 60Hz |
| Serial | 1x RS-232 |
| Onboard Storage | 32GB eMMC |
| Maximum Power | 15W + Mezzanine Power |
| Back Plane PCIe | Two x4 PCIe Gen3.0 Capable Backplane Ports |
| LEDs | PCIe Link speeds, Power up status |
| Thermal Interface | Conduction cooled |
Ordering information:
VPG003-22 Graphite VPX/CPU – TX2, EU/Japan
Cables/Accessories
RTG004 RTM for Development on the VPG003 CPU board
