Opis
Dane techniczne:
| Dimensions | 42 mm x 22 mm (M.2 Type-2242-S3-B) 30 mm x 22 mm (M.2 Type 2230-E Key) M2G207 Only |
|---|---|
| Antenna Connector | HSC (MHFA) (Support for active antennas only) |
| Antenna | MSG095, Active GPS/GLONASS Antennas only, VTGPSA-9 |
| GPS | GPS, GLONASS, QZSS, Galileo UBX, RTCM, and NMEA protocols |
| I/O | External Battery input, External Interrupt input, Forward/Reverse and Wheeltick inputs for Automotive Dead Reckoning, TIMEPULSE output syncronized with GPS time grid |
| Cables | CBG162 (IO Connector Cable), CBG214 (RF Connector to SMA) |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
Ordering information:
M2G201 M.2 GPS Receiver (Battery not included) populated with NEO-7N module
M2G202 M.2 GPS Receiver (Battery included) populated with NEO-7N module
M2G203 M.2 GPS Receiver (Battery not included) populated with NEO-M8N module
M2G204 M.2 GPS Receiver (Battery included) populated with NEO-M8N module
M2G205 M.2 GPS Receiver (Battery not included) populated with NEO-M8L module, supports Automotive Dead Reckoning
M2G206 M.2 GPS Receiver (Battery included) populated with NEO-M8L module, supports Automotive Dead Reckoning
M2G207 M.2 GPS Receiver (Battery included) populated with NEO-7N module; E-key
Cables/Accessories
MSG095 GPS External Active Antenna
CBG162 External I/O Cable
CBG214 Murata HSC to SMA Female Cable
