Description
Dane techniczne:
| Compatibility | ADG075: Single Mini PCIe, ADG077: Dual Mini PCIe |
|---|---|
| I/O | 1x USB 2.0, ADG077: 4-Port Hub, Oversize Mini PCIe Module, PCI-104 (Pass Through), SIM Socket, Type 1 or Type 2 PCIe/104 |
| Dimensions | 95.885mm x 90.17mm (3.775″ x 3.550″) |
| Power Requirements | +5V (PCIe/104 Bus Supplied) |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
Ordering information:
ADG075 Single Oversized Rugged Mini-PCIe Carrier Without PCI-104 Pass Through
ADG077 Dual Rugged Mini-PCIe Carrier Without PCI-104 Pass Through
ADG097 Dual Rugged Mini-PCIe Carrier With PCI-104 Pass Through
ADG098 Single Oversized Rugged Mini-PCIe Carrier With PCI-104 Pass Through
