Description
Dane techniczne:
| Power Requirements | +9V to +36V |
|---|---|
| Power Consumption | 2250V Max |
| Output Voltage Rails | +3.3V, +5V and +12V |
| Total Output Power | Up to 195W |
| Dimensions | PC/104 Compliant |
| Bus Expansion Options | PC/104-Plus (PCI & ISA), PC/104 (ISA Only), PCI-104 (PCI Only), PCIe/104 (PCI Express Only), PCI/104-Express (PCI Express & PCI), Embedded (No Bus Connectors) |
| Input Protection | Reverse polarity protection, transient voltage suppression and series fuse |
| Efficiency | Maximum 92% |
| Output Ripple/Noise | Less than 100mV p-p |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Output Protection | Overload protection and transient voltage suppression |
| Control | Remote ON/OFF functionality |
Ordering informations:
PXG101 Xtreme/PSU Isolated Power Supply – SP (PC/104-Plus)
PXG102 Xtreme/PSU Isolated Power Supply – SP (PC/104)
PXG103 Xtreme/PSU Isolated Power Supply – SP (PCI-104)
PXG104 Xtreme/PSU Isolated Power Supply – SP (PCIe/104)
PXG105 Xtreme/PSU Isolated Power Supply – SP (PCI/104-Express)
PXG106 Xtreme/PSU Isolated Power Supply – SP (Embedded)
PXG107 Xtreme/PSU Isolated Power Supply – SP (PC/104-Plus)
PXG108 Xtreme/PSU Isolated Power Supply – SP (PC/104)
PXG109 Xtreme/PSU Isolated Power Supply – SP (PC/104)
PXG110 Xtreme/PSU Isolated Power Supply – SP (PCIe/104)
PXG111 Xtreme/PSU Isolated Power Supply – SP (PCI/104-Express)
PXG112 Xtreme/PSU Isolated Power Supply – SP (Embedded)
PXG201 Xtreme/PSU Isolated Power Supply – LP (PC/104-Plus)
PXG202 Xtreme/PSU Isolated Power Supply – LP (PC/104)
PXG203 Xtreme/PSU Isolated Power Supply – LP (PCI-104)
PXG204 Xtreme/PSU Isolated Power Supply – LP (PCIe/104)
PXG205 Xtreme/PSU Isolated Power Supply – LP (PCI/104-Express)
PXG206 Xtreme/PSU Isolated Power Supply – LP (Embedded)
PXG301 Xtreme/PSU Isolated Power Supply – HP (PC/104-Plus)
PXG302 Xtreme/PSU Isolated Power Supply – HP (PC/104)
PXG303 Xtreme/PSU Isolated Power Supply – HP (PCI-104)
PXG304 Xtreme/PSU Isolated Power Supply – HP (PCIe/104)
PXG305 Xtreme/PSU Isolated Power Supply – HP (PCI/104-Express)
PXG306 Xtreme/PSU Isolated Power Supply – HP (Embedded)
PXG307 Xtreme/PSU Isolated Power Supply – HP (PC/104-Plus)
PXG308 Xtreme/PSU Isolated Power Supply – HP (PC/104)
PXG309 Xtreme/PSU Isolated Power Supply – HP (PC/104)
PXG310 Xtreme/PSU Isolated Power Supply – HP (PCIe/104)
PXG311 Xtreme/PSU Isolated Power Supply – HP (PCI/104-Express)
PXG312 Xtreme/PSU Isolated Power Supply – HP (Embedded)
