Description
Dane techniczne:
| Dimensions | PC/104 Compliant |
|---|---|
| Bus | Embedded (No Bus Connectors) option, PCI-104 (PCI) option |
| Power Requirements | +6V to +36V DC Input |
| Input Protection | Reverse polarity protection, transient voltage suppression and series fuse |
| Power Consumption | 154W |
| +3.3V Output | 10A maximum continuous for full -40 to +85 range |
| +5V Output | 10A maximum continuous for full -40 to +85 range |
| -12V Output | 0.5A maximum continuous for full -40 to +85 range |
| +5V Standby | 1A maximum continuous for full -40 to +85 range |
| Output Regulation | Less than 1% |
| Output Protection | Overload protection and transient voltage suppression |
| Output Efficiency | Up to 93% |
| Battery | Fully compatible with all SMART external batteries, Supporting charging up to 16V, 4A |
| Monitor/Control | On-board USB, RS-232 and SMbus interfaces for battery monitoring and power on/off control |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Connectors | Input: 5mm pitch standard terminal block header and mating plug, Output: 3.5mm pitch standard terminal block header and mating plug |
Ordering informations:
SCG001 PCI-104 Build
– +5V @ 10A, +3.3V @10A,+12V @ 5A, -12V @0.5A, +5VSB @ 1A
– +5V, +3.3V**, +12V and -12V connected to PCI-104 Bus connector.
SCG002 Embedded Build
– +5V @ 10A, +3.3V @10A,+12V @ 5A, -12V @0.5A, +5VSB @ 1A
